Intro
With the PDF Library for Android by WINSOFT, you can create, process, and render PDF documents in your Delphi/C++ Builder FireMonkey Android applications.
The PDF Library for Android by WINSOFT uses the PdfBox-Android library. So, this is our main library here. Because the PdfBox-Android library offers full control over PDF documents.
The library by the WINSOFT allows us to easily talk with the PdfBox-Android library. You may use IDE Software to integrate the PdfBox-Android library for full optimization and control of PDF documents when creating Android applications.
Specifications
- Uses PdfBox-Android library
- Available for Delphi/C++ Builder 10 – 10.4
Overview
The first thing is to configure the library into your RAD Studio. Please, follow this short tutorial if you don’t have a component/library installing/configuring experience!
Also, watch see this demo action video that shows how this PDF library works in a Delphi FireMonkey application
Development
Every Android application runs in a limited sandbox. If an application needs permission to do something inside Android OS, you should get permission.
Requesting permission is easy in Delphi/C++ Builder FireMonkey. So, you should request a write external storage permission and then you can start processing PDF documents.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 |
procedure TFormMain.ButtonCreatePdfClick(Sender: TObject); begin {$ifdef D103PLUS} PermissionsService.RequestPermissions([ JStringToString(TJManifest_permission.JavaClass.WRITE_EXTERNAL_STORAGE)], procedure(const APermissions: TArray<string>; const AGrantResults: TArray<TPermissionStatus>) begin if (Length(AGrantResults) = 1) and (AGrantResults[0] = TPermissionStatus.Granted) then CreatePdf else ShowMessage('Permission denied'); end); {$else} CreatePdf; {$endif D103PLUS} end; |
Here is our CreatePdf procedure which initializes PDF library, creates a Pdf Document object, adds a new page, and creates a content stream.
You have many features that you can use, for instance:
- Adding Text Content
- Utilize Unicode Font
- Draw Lines
- Draw Shapes
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 |
procedure TFormMain.CreatePdf; var Document: TPdfDocument; Page: TPdfPage; PageHeight: Single; UnicodeFont: TPdfFont; Content: TPdfPageContentStream; DashPattern: TSingleDynArray; CenterX, CenterY: Single; Matrix: TPdfMatrix; FileName: string; begin PdfLibrary.Initialize; Document := TPdfDocument.Create; try Document.Creator := 'PDF Library for Android'; Document.CreationDate := Now; Page := Document.AddPage; try PageHeight := -Page.MediaBox.Height; Content := Page.CreateContentStream; try // add text Content.BeginText; Content.NonStrokingColor(TAlphaColorRec.Green); Content.Font(TPdfFont.Helvetica, 16); Content.NewLineAtOffset(20, PageHeight - 20); Content.Text('Hello, world!'); Content.Font(TPdfFont.HelveticaBold, 24); Content.NewLineAtOffset(0, -30); Content.Text('Hello, world!'); UnicodeFont := Document.LoadFontAsset('com/tom_roush/pdfbox/resources/ttf/LiberationSans-Regular.ttf'); try Content.Font(UnicodeFont, 24); Content.NewLineAtOffset(0, -30); Content.Text('Hello, World!'); Content.EndText; // draw lines Content.StrokingColor(TAlphaColorRec.Orange); Content.LineWidth(2); Content.MoveTo(20, PageHeight - 100); Content.LineTo(100, PageHeight - 100); Content.Stroke; Content.LineWidth(4); Content.LineCapStyle(TPdfLineCapStyle.lcRound); Content.MoveTo(20, PageHeight - 114); Content.LineTo(150, PageHeight - 114); Content.Stroke; SetLength(DashPattern, 2); DashPattern[0] := 4; DashPattern[1] := 2; Content.LineWidth(8); Content.LineCapStyle(TPdfLineCapStyle.lcButt); Content.LineDashPattern(DashPattern); Content.MoveTo(20, PageHeight - 132); Content.LineTo(200, PageHeight - 132); Content.Stroke; // draw rectangles Content.StrokingColor(TAlphaColorRec.Red); Content.LineWidth(2); Content.Rectangle(TRectF.Create(20, PageHeight - 150, 100, PageHeight - 230)); Content.Stroke; Content.NonStrokingColor(TAlphaColorRec.Red); Content.Rectangle(TRectF.Create(120, PageHeight - 150, 200, PageHeight - 230)); Content.Fill; CenterX := 110; CenterY := PageHeight - 300; Matrix := TPdfMatrix.Create; try Matrix.Translate(CenterX, CenterY); Matrix.Rotate(DegToRad(45)); Matrix.Translate(-CenterX, -CenterY); Content.NonStrokingColor(TAlphaColorRec.LightBlue); Content.Transform(Matrix); Content.Rectangle(TRectF.Create(CenterX - 40, CenterY - 40, CenterX + 40, CenterY + 40)); Content.Fill; Content.StrokingColor(TAlphaColorRec.Blue); Content.LineWidth(2); Content.Rectangle(TRectF.Create(CenterX - 40, CenterY - 40, CenterX + 40, CenterY + 40)); Content.Stroke; Content.Close; // render to bitmap ImageViewer.Bitmap := Document.RenderPage(0); // save to file FileName := TPath.GetSharedDocumentsPath + PathDelim + 'new.pdf'; Document.Save(FileName); ShowMessage('File ' + FileName + ' created'); finally Matrix.Free; end; finally UnicodeFont.Free end; finally Content.Free; end; finally Page.Free; end; finally Document.Free; end; end; |
Head over and check out the full WINSOFT PDF Library for Android
